Solar Bracket System

Specification

Single-axis tracking system is scientifically designed and precision calculated to fully guarantee the mechanical strength of each component.The polymer material bearing can effectivelly prevent sand dust, rain and snow erosion. The anti-shadow design effectively avoids shadow blocking problems in the morning and evening and increases power generation. Intelligent electrical control ensures long term reliability and easy maintenance.

Foundation Type	Concrete foundation
Drive Type	Rotary reducer+linear actuator
Installation Capacity	5KW-10KW/row
Tracking Range	±60°
Control Type	MCU
Tracking accuracy	0.5°C
Protection Wind Speed	≥18m/s(or customer specified)
Wind Resistance	≤33m/s(or customer specified)
Executive Standard	"Code for design of steel structure" GB50017;
	"Building structure load specification" GB50009
	"CPP wind tunnel test report", ALSC360-10,ASCE7-10
Protection Level	IP66
Ambient Temperature	-40°C-70°C
System Voltage	380V
Monitoring Device	Remote Monitoring(optional)
Warranty	15years
